The automatic clothing rhinestone application machine

The automatic clothing rhinestone application machine is an automated device used for decorating clothing with rhinestones. It transforms the traditional manual rhinestone application process into a mechanical automated operation, improving production efficiency and reducing labor costs. Below is a detailed introduction to the automatic clothing rhinestone application machine:

Contact Information

Contact : LaserAutomation@qq.com Engineer Zheng (+86)137 3655 8515 WhatsApp & Wechat

Working Principle

The automatic rhinestone application machine mainly consists of an elastic horizontal working table, a feeding hopper, a hopper support, a hopper fixing frame, a sweeping bar, a power motor, and other components. The working process is as follows:

  1. Feeding and Movement: The feeding hopper is placed horizontally on the working table. The gap between the hopper and the table can be adjusted vertically. Driven by the motor, the hopper support moves horizontally back and forth in the Y-axis direction, while following the hopper fixing frame to move horizontally back and forth in the X-axis direction.
  2. Rhinestone Application: Decorative rhinestones or other materials enter the working table through the feeding hopper. Under the combined action of the hopper’s horizontal movement and reciprocating motion, the rhinestones are evenly brushed into the pattern template of the rhinestone application.
  3. Cleaning: The sponge velvet strip on the sweeping bar removes excess decorative material from the template surface during the reciprocating movement of the hopper fixing frame, completing the rhinestone application process.

Technical Parameters

  • Rhinestone Application Speed: 25-35 pieces per minute.
  • Power Supply Voltage: 220V.
  • Power: 500W.
  • Weight: Approximately 60KG.
  • Machine Dimensions: 1100×1300×1000mm.

Advantages

  • High Efficiency: It can quickly complete the rhinestone application of multi-color or various sizes of rhinestones, improving production efficiency.
  • Precise Color Matching: The fully automatic rhinestone application machine uses deviation correction compensation technology to ensure precise color matching.
  • Easy Operation: It reduces manual operation steps and lowers the skill requirements for operators.
  • Cost Reduction: A single machine can replace 7-10 workers, significantly reducing labor costs.
